CS-Laser encoding system
Laser, magnetic, and RFID personalization for cards
The CS laser system from Rinas Gerätetechnik is a modular coding system for laser personalization of magnetic cards, RFID cards, and chip cards. It processes cards made of plastic, wood, or metal with the highest precision.
Thanks to its modular design, the system can be configured with one or two laser units. An integrated flip unit enables double-sided processing in a single pass – ideal for high volumes and precise coding.
Card encoding with laser precision
The CS laser coding system combines laser engraving, magnetic coding, RFID, and chip personalization in one compact system. The layout editor allows you to freely define labels, barcodes, and security features.
The system supports ISO 7811 magnetic encoding, Mifare and Legic RFID chips, and contact-based smart chip encoding. Standardized interfaces allow the system to be seamlessly integrated into existing production lines.
Technical advantages of laser coding systems
- Laser, magnetic, and RFID coding in one system
- Modular design for OEM integration
- Low maintenance according to the Think Green concept
- Precise engraving and layout control
- Energy-efficient power supply with 24 V DC
Card parameters
Card sizes (ID-1)
- Length: 85.7 mm
- Width: 54.0 mm
Card thickness
- 0.5 mm to 1.2 mm
Types of cards
- All colors
- Transparent cards
Parameter coding and accessories
Magnetic strip
- LOCO: up to 3 tracks
- HICO: up to 3 tracks
- 300 Oe to 4,000 Oe
Coding
- Free bit encoding
- Customized
Magnetic strip layer
- Bottom right
Standards
- ISO 7811, JIS, Visa Mini Card, AAMVA
RFID
- Mifare/Legic, etc. (antenna dependent)
Chip coding
- Rina's contact unit (consumer electronics)
Scanner
For data acquisition or control of laser data
- Barcodes (common)
- Matrix code (common)
- OCR reading
Laser module
- Monochrome
- Laser size ID-1
- Media: Plastic, wood, metal
- Laser speed depending on data volume
Machine parameters
HICO/LOCO throughput
- approx. 2,400 cph
Dimensions L/W/H (mm)
- Depending on configuration, from 1000 x 800 x 1700
Weight
- from approx. 80 kg
Control
- 1x USB
- 4x digital outputs
- 4x digital inputs
Capacities (0.76 mm)
- Card separator: 500 cards
- Card unloader: 500 cards
- Other sizes optional
maintenance times
- Cleaning depending on the medium used
Power
- 230V AC for laser
- +24VDC (160W) machine
Let's talk about your project
We analyze your application, recommend the appropriate systems and modules, and demonstrate integration, including realistic cycle times.
